10 HP Single Stage Screw Air Compressor

10 HP Direct Driven Single Stage Screw Air Compressor

Our 10 HP Direct Driven Single Stage Screw Air Compressor available in Standard Fix Models. We use PM Motor with our VFD Models, which decrease the energy consumption substantially to save even more energy as well as money.

Features:

• Super premium efficiency IE4 PM motor

• Vibration free quieter operation

• Designed for hot indian climate

• Service friendly design

• Direct drive with low rpm

• Advance PLC for easy operation

• Lowest oil carry over

• Lowest life cycle cost

Technical Specifications – 10 HP Screw Air Compressor (Model: CTSD 10)

Horse Power : 10 HP

Compressor Technology : Screw Compressor

Power Source : AC Three Phase

Model Name/Number : CTSD 10

Air Quality Standard : Class I

Number of Compression Stages : Single Stage

Weight : 400 kg

Dimension : (L × W × H) 34 x 26 x 44 inch

Warranty : 12 Months

Cooling Method : Air Cooled

Brand : Comptech

Sound Level : 68 dB

FAD Capacity : 40 CFM at 8 kg/cm², 35 CFM at 10 kg/cm²

Compressor Speed : 2900 RPM
