120 HP Single Stage Screw Air Compressor

120 HP Direct Driven Single Stage Screw Air Compressor

Our 120 HP Direct Driven Single Stage Screw Air Compressor available in Standard Fix Models. We use PM Motor with our VFD Models, which decrease the energy consumption substantially to save even more energy as well as money.

Features:

• Super premium efficiency IE4 PM motor

• Vibration free quieter operation

• Designed for hot indian climate

• Service friendly design

• Direct drive with low rpm

• Advance PLC for easy operation

• Lowest oil carry over

• Lowest life cycle cost

Technical Specifications – 120 HP Screw Air Compressor (Model: CTSD 120)

Horse Power : 120 HP

Power Source : AC Three Phase

Model Name/Number : CTSD 120

Number of Compression Stages : Single Stage

Weight : 1900 kg

Compressor Technology : Screw Compressor

Dimension : (L × W × H) 79 x 58 x 70 inch

Warranty : 12 Months

Cooling Method : Air Cooled

Compressor Speed : 2900 RPM

Brand Name : Comptech

Sound Level : 76 dB

FAD Capacity : 554 CFM at 8 kg/cm², 543 CFM at 10 kg/cm²
