'phase reliable machine'

20 HP Reciprocating Air Compressor Motor Power 20 HP Tank Capacity 500 L Brand Comptech Cooling System Air Cooled Maximum Flow Rate(CFM) 77 No. of Cylinders 3 Stages Double Stage Power Phase Three Phase reliable machine used to compress air for various applications. It works by using a piston that moves back and forth to compress the air inside a cylinder, making it ideal for powering tools, inflating tires, and more. At Comptech Equipments Limited, we provide high-quality reciprocating air compressors designed for durability, efficiency, and long-lasting performance. Perfect for industries and workshops, our compressors are easy to use and maintain.

150 HP Pharma Industries Medium Pressure Oil Free 2 Stage Air Compressor • Oil Free Medium Pressure have Forged Crank Shaft & Connecting Rod, Precision Main & Crank Pin Bearings with force feed lubrication have very high load bearing capacity & hardly needs replacements. • Low RPM & rugged cast iron design ideal for heavy duty continuous 24 x 7 operating year after year. • Cylinders constructed with large cast in water jackets & specially designed intercoolers for dimensional stability & better cooling under continuous operation. Features: • 100% oil free air • Vibration free quieter operation • Sustainable design for decades • Service friendly design • Lowest area occupancy • Advance PLC for easy operation • Premium efficiency IE3 motor • Lowest life cycle cost Technical Specifications – 150 HP Oil-Free Reciprocating Air Compressor (Model: CTBO 10-150) Horse Power : 150 HP Maximum Flow Rate : 644 CFM Model Name/Number : CTBO 10-120 Brand : Comptech Air Tank Capacity : 3000 Litre Compressor Technology : Reciprocating Compressor Power Source : AC Three Phase Warranty : 12 Months Cooling Method : Water Cooled Lubrication Style : Oil Free

120 HP Pharma Industries Medium Pressure Oil Free 2 Stage Air Compressor • Oil Free Medium Pressure have Forged Crank Shaft & Connecting Rod, Precision Main & Crank Pin Bearings with force feed lubrication have very high load bearing capacity & hardly needs replacements. • Low RPM & rugged cast iron design ideal for heavy duty continuous 24 x 7 operating year after year. • Cylinders constructed with large cast in water jackets & specially designed intercoolers for dimensional stability & better cooling under continuous operation. Features: • 100% oil free air • Vibration free quieter operation • Sustainable design for decades • Service friendly design • Lowest area occupancy • Advance PLC for easy operation • Premium efficiency IE3 motor • Lowest life cycle cost Technical Specifications – 120 HP Oil-Free Reciprocating Air Compressor (Model: CTBO 10-120) Horse Power : 120 HP Maximum Flow Rate : 644 CFM Model Name/Number : CTBO 10-120 Brand : Comptech Air Tank Capacity : 3000 Litre Compressor Technology : Reciprocating Compressor Power Source : AC Three Phase Warranty : 12 Months Cooling Method : Water Cooled Lubrication Style : Oil Free

75 HP Pharma Industry Medium Pressure Oil Free Air Compressor • Oil Free Medium Pressure have Forged Crank Shaft & Connecting Rod, Precision Main & Crank Pin Bearings with force feed lubrication have very high load bearing capacity & hardly needs replacements. • Low RPM & rugged cast iron design ideal for heavy duty continuous 24 x 7 operating year after year. • Cylinders constructed with large cast in water jackets & specially designed intercoolers for dimensional stability & better cooling under continuous operation. Features: • 100% oil free air • Vibration free quieter operation • Sustainable design for decades • Service friendly design • Lowest area occupancy • Advance PLC for easy operation • Premium efficiency IE3 motor • Lowest life cycle cost Technical Specifications – 75 HP Oil-Free Reciprocating Air Compressor (Model: CTBO 10-75) Horse Power : 75 HP Air Tank Capacity : 2000 Litre Maximum Flow Rate : 324 CFM Model Name/Number : CTBO 10-75 Brand : Comptech Power Source : AC Three Phase Warranty : 12 Months Lubrication Style : Oil Free Discharge Pressure : 10 kg/cm²g

120 HP Direct Driven Single Stage Screw Air Compressor Our 120 HP Direct Driven Single Stage Screw Air Compressor available in Standard Fix Models. We use PM Motor with our VFD Models, which decrease the energy consumption substantially to save even more energy as well as money. Features: • Super premium efficiency IE4 PM motor • Vibration free quieter operation • Designed for hot indian climate • Service friendly design • Direct drive with low rpm • Advance PLC for easy operation • Lowest oil carry over • Lowest life cycle cost Technical Specifications – 120 HP Screw Air Compressor (Model: CTSD 120) Horse Power : 120 HP Power Source : AC Three Phase Model Name/Number : CTSD 120 Number of Compression Stages : Single Stage Weight : 1900 kg Compressor Technology : Screw Compressor Dimension : (L × W × H) 79 x 58 x 70 inch Warranty : 12 Months Cooling Method : Air Cooled Compressor Speed : 2900 RPM Brand Name : Comptech Sound Level : 76 dB FAD Capacity : 554 CFM at 8 kg/cm², 543 CFM at 10 kg/cm²

75 HP Direct Driven Single Stage Screw Air Compressor Our 75 HP Direct Driven Single Stage Screw Air Compressor available in Standard Fix Models. We use PM Motor with our VFD Models, which decrease the energy consumption substantially to save even more energy as well as money. Features: • Super premium efficiency IE4 PM motor • Vibration free quieter operation • Designed for hot indian climate • Service friendly design • Direct drive with low rpm • Advance PLC for easy operation • Lowest oil carry over • Lowest life cycle cost Technical Specifications – 75 HP Screw Air Compressor (Model: CTSD 75) Horse Power : 75 HP Compressor Technology : Screw Compressor Power Source : AC Three Phase Model Name/Number : CTSD 75 Number of Compression Stages : Single Stage Weight : 1150 kg Dimension : (L × W × H) 73 x 42 x 67 inch Warranty : 12 Months Cooling Method : Air Cooled Compressor Speed : 2900 RPM Sound Level : 75 dB FAD Capacity : 356 CFM at 8 kg/cm², 321 CFM at 10 kg/cm² Brand Name : Comptech

60 HP Direct Driven Single Stage Screw Air Compressor Our 60 HP Direct Driven Single Stage Screw Air Compressor available in Standard Fix Models. We use PM Motor with our VFD Models, which decrease the energy consumption substantially to save even more energy as well as money. Features: • Super premium efficiency IE4 PM motor • Vibration free quieter operation • Designed for hot indian climate • Service friendly design • Direct drive with low rpm • Advance PLC for easy operation • Lowest oil carry over • Lowest life cycle cost Technical Specifications – 60 HP Screw Air Compressor (Model: CTSD 60) Horse Power : 60 HP Model Name/Number : CTSD 60 Number of Compression Stages : Single Stage Weight : 960 kg Power Source : AC Three Phase Air Quality Standard : Class I Compressor Speed : 2900 RPM Warranty : 12 Months Dimension : (L × W × H) 73 x 42 x 67 inch Sound Level : 74 dB FAD Capacity : 275 CFM at 8 kg/cm², 254 CFM at 10 kg/cm² Brand Name : Comptech

50 HP Direct Driven Single Stage Screw Air Compressor Our 50 HP Direct Driven Single Stage Screw Air Compressor available in Standard Fix Models. We use PM Motor with our VFD Models, which decrease the energy consumption substantially to save even more energy as well as money. Features: • Super premium efficiency IE4 PM motor • Vibration free quieter operation • Designed for hot indian climate • Service friendly design • Direct drive with low rpm • Advance PLC for easy operation • Lowest oil carry over • Lowest life cycle cost Technical Specifications – 50 HP Screw Air Compressor (Model: CTSD 50) Horse Power : 50 HP Power Source : AC Three Phase Model Name/Number : CTSD 50 Number of Compression Stages : Single Stage Weight : 800 kg Compressor Technology : Screw Compressor Dimension : (L × W × H) 57 x 35 x 58 inch Warranty : 12 Months Cooling Method : Air Cooled Air Quality Standard : Class I Compressor Speed : 2900 RPM Brand Name : Comptech FAD Capacity : 232 CFM at 8 kg/cm², 215 CFM at 10 kg/cm²

25 HP Direct Driven Single Stage Screw Air Compressor Our 25 HP Direct Driven Single Stage Screw Air Compressor available in Standard Fix Models. We use PM Motor with our VFD Models, which decrease the energy consumption substantially to save even more energy as well as money. Features: • Super premium efficiency IE4 PM motor • Vibration free quieter operation • Designed for hot indian climate • Service friendly design • Direct drive with low rpm • Advance PLC for easy operation • Lowest oil carry over • Lowest life cycle cost Technical Specifications – 25 HP Screw Air Compressor (Model: CTSD 25) Horse Power : 25 HP Brand : Comp Tech Power Source : AC Three Phase Model Name/Number : CTSD 25 Number of Compression Stages : Single Stage Weight : 550 kg Compressor Technology : Screw Compressor Dimension : (L × W × H) 49 x 30 x 51 inch Warranty : 12 Months Cooling Method : Air Cooled Air Quality Standard : Class I Sound Level : 71 dB FAD Capacity : 110 CFM at 8 kg/cm², 100 CFM at 10 kg/cm² Compressor Speed : 2900 RPM
