25 HP Direct Driven Single Stage Screw Air Compressor Our 25 HP Direct Driven Single Stage Screw Air Compressor available in Standard Fix Models. We use PM Motor with our VFD Models, which decrease the energy consumption substantially to save even more energy as well as money. Features: • Super premium efficiency IE4 PM motor • Vibration free quieter operation • Designed for hot indian climate • Service friendly design • Direct drive with low rpm • Advance PLC for easy operation • Lowest oil carry over • Lowest life cycle cost Technical Specifications – 25 HP Screw Air Compressor (Model: CTSD 25) Horse Power : 25 HP Brand : Comp Tech Power Source : AC Three Phase Model Name/Number : CTSD 25 Number of Compression Stages : Single Stage Weight : 550 kg Compressor Technology : Screw Compressor Dimension : (L × W × H) 49 x 30 x 51 inch Warranty : 12 Months Cooling Method : Air Cooled Air Quality Standard : Class I Sound Level : 71 dB FAD Capacity : 110 CFM at 8 kg/cm², 100 CFM at 10 kg/cm² Compressor Speed : 2900 RPM

20 HP Direct Driven Single Stage Screw Air Compressor Our 20 HP Direct Driven Single Stage Screw Air Compressor available in Standard Fix Models. We use PM Motor with our VFD Models, which decrease the energy consumption substantially to save even more energy as well as money. Features: • Super premium efficiency IE4 PM motor • Vibration free quieter operation • Designed for hot indian climate • Service friendly design • Direct drive with low rpm • Advance PLC for easy operation • Lowest oil carry over • Lowest life cycle cost Technical Specifications – 20 HP Screw Air Compressor (Model: CTSD 20) Horse Power : 20 HP Power Source : AC Three Phase Model Name/Number : CTSD 20 Brand : Comptech Number of Compression Stages : Single Stage Weight : 450 kg Compressor Technology : Screw Compressor Dimension : (L × W × H) 36 x 30 x 43 inch Warranty : 12 Months Cooling Method : Air Cooled Air Quality Standard : Class I Sound Level : 70 dB Compressor Speed : 2900 RPM FAD Capacity : 85 CFM at 8 kg/cm², 77 CFM at 10 kg/cm²

10 HP Direct Driven Single Stage Screw Air Compressor Our 10 HP Direct Driven Single Stage Screw Air Compressor available in Standard Fix Models. We use PM Motor with our VFD Models, which decrease the energy consumption substantially to save even more energy as well as money. Features: • Super premium efficiency IE4 PM motor • Vibration free quieter operation • Designed for hot indian climate • Service friendly design • Direct drive with low rpm • Advance PLC for easy operation • Lowest oil carry over • Lowest life cycle cost Technical Specifications – 10 HP Screw Air Compressor (Model: CTSD 10) Horse Power : 10 HP Compressor Technology : Screw Compressor Power Source : AC Three Phase Model Name/Number : CTSD 10 Air Quality Standard : Class I Number of Compression Stages : Single Stage Weight : 400 kg Dimension : (L × W × H) 34 x 26 x 44 inch Warranty : 12 Months Cooling Method : Air Cooled Brand : Comptech Sound Level : 68 dB FAD Capacity : 40 CFM at 8 kg/cm², 35 CFM at 10 kg/cm² Compressor Speed : 2900 RPM

10 HP Tank Mounted Direct Driven Screw Air Compressor Horse Power : 10 HP Brand : Comp Tech Power Source : AC Three Phase Compressor Technology : Screw Compressor Model Name/Number : CTSD 10 Cooling Method : Air Cooled Dimension : 34 x 26 x 44 inch (L x W x H) Warranty : 12 months Weight : 400 kg Mounting Type : Tank Mounted Number Of Compression Stages : Single Stage Sound Level : 68 dB Compressor Speed : 2900 rpm FAD Capacity : 40 cfm at 8 kg/cm2, 35 cfm at 10 kg/cm2 Country of Origin : Made in India Our 10 HP Tank Mounted Direct Driven Screw Air Compressor available in Standard Fix Models. We use PM Motor with our VFD Models, which decrease the energy consumption substantially to save even more energy as well as money. Other Details: Mounted on Air Receiver Features: Super premium efficiency IE4 PM motor Vibration free quieter operation Designed for hot indian climate Service friendly design Direct drive with low rpm Advance PLC for easy operation Lowest oil carry over Lowest life cycle cost

30 HP Screw Air Compressor Motor Power : 30 HP Brand: Comptech Cooling System: Air Cooled Maximum Pressure: 16 Bar Maximum Flow Rate(CFM): 152 CFM Compressor Type: Screw Compressor Our 30 HP Screw Air Compressor available in Standard Fix Models. We use PM Motor with our VFD Models, which decrease the energy consumption substantially to save even more energy as well as money. Features: Super premium efficiency IE4 PM motor Vibration free quieter operation Designed for hot indian climate Service friendly design Direct drive with low rpm Advance PLC for easy operation Lowest oil carry over Lowest life cycle cost

50 HP Screw Air Compressor Horse Power : 50 HP Brand : Comptech Model Name/Number : CTS II 50 Compressor Noise Level : 73 dB Number Of Compression Stages : Two Stage Compressor Technology : Screw Compressor Warranty : 12 months Cooling Method : Air Cooled Air Quality Standard : Class I Compressor Speed : 1450 rpm Working Pressure : 5 bar g FAD Capacity : 326 cfm A 2-Stage Screw Air Compressor Series designed to enhance the profitability of your production. The regulated speed models, or VFD+ models, save energy by matching the output to the plant's air demand, with the added benefit of high-efficiency internal Permanent Magnet Motors, ensuring no loss of efficiency. Other Details: Equipped with VFD & IE4 PM Motor Features: Best-in-class efficiency Premium efficiency 2-stage air-end Longer lifespan due to low motor RPM Available with super-premium options Low noise and minimal vibrations Lowest cost of ownership in the market 50,000 hours bearing life Specifications: Working Pressure: 8 bar g, 10 bar g FAD Capacity: 258 cfm, 234 cfm

20 HP Tank Mounted Direct Driven Screw Air Compressor Horse Power : 20 HP Model : Name/Number CTSD 20 Weight : 450 kg Compressor Technology : Screw Compressor Dimension : 36 x 30 x 43 inch (L x W x H) Warranty : 12 months Cooling Method : Air Cooled Air Quality Standard : Class I FAD Capacity : 85 cfm at 8 kg/cm2, 77 cfm at 10 kg/cm2 Number Of Compression Stages : Single Stage Mounting Type : Tank Mounted Sound Level : 70 dB Brand Name : Comptech Compressor Speed : 2900 rpm Our 20 HP Tank Mounted Direct Driven Screw Air Compressor available in Standard Fix Models. We use PM Motor with our VFD Models, which decrease the energy consumption substantially to save even more energy as well as money. Other Details: Mounted on Air Receiver Features: Super premium efficiency IE4 PM motor Vibration free quieter operation Designed for hot indian climate Service friendly design Direct drive with low rpm Advance PLC for easy operation Lowest oil carry over Lowest life cycle cost

75 HP Direct Driven Single Stage Screw Air Compressor Horse Power : 75 HP Compressor Technology : Screw Compressor Brand : Comp Tech Power Source : AC Three Phase Model : Name/Number CTSD 75 Number Of Compression Stages : Single Stage Weight : 1150 kg Dimension : 73 x 42 x 67 inch (L x W x H) Warranty : 12 months Cooling Method : Air Cooled FAD Capacity : 356 cfm at 8 kg/cm2, 321 cfm at 10 kg/cm2 Sound Level : 75 dB Compressor Speed : 2900 rpm Country of Origin : Made in India Our Screw Air Compressor available in Standard Fix Models. We use PM Motor with our VFD Models, which decrease the energy consumption substantially to save even more energy as well as money. Features: Super premium efficiency IE4 PM motor Vibration free quieter operation Designed for hot indian climate Service friendly design Direct drive with low rpm Advance PLC for easy operation Lowest oil carry over Lowest life cycle cost

180 HP Direct Driven Screw Air Compressor Air Tank Capacity : 3000 L Maximum Flow Rate : 923 CFM Power Source : Electric Model Name/Number : CTSD 180 Brand : Comptech Horse Power : 180 HP Weight : 2500 kg Noise Level : 76 dB FAD : 773 (10 kg/cm2) Compressor : 2900 RPM Dimension : 92x61x75 inch We are among the reputed organizations, highly engaged in providing an optimum quality range of 180 HP Screw Air Compressor. The CTSD range is a Direct Electric motor driven Stationery, Single stage, Air cooled, and Oil lubricated, Rotary Screw Air Compressor package housed in acoustic enclosure. • Energy saving gearless one to one Direct Drive Air end. • Heavy duty dry types Suction Air filter with 99.9% efficient @ 3 microns and above. • Integrated new generation Intake Valve controls the compressor capacity to meet down-stream air demand

25 HP Reciprocating Compressor Motor Power : 25 HP Air Tank Capacity : 300 L Brand : Comptech Cooling System : Air Cooled Maximum Flow Rate(CFM) : 77 cfm Maximum Pressure : 35 Bar Number of Compression Stages : Single Stage The 25 HP Reciprocating Air Compressor is designed for optimal performance in applications requiring medium air pressure. These compressors are widely used across industries for their reliability, efficiency, and ease of maintenance. Key Features: Single-Stage Compression: Air is compressed in a single stroke, delivering up to 100 PSI pressure, suitable for various light to moderate applications. Air-Cooled Design: Effective heat dissipation ensures consistent performance without the need for water cooling. High Durability: Constructed with premium-grade materials to withstand challenging environments. Energy Efficiency: Engineered to consume less power while delivering maximum output. Compact and Portable: Space-saving design allows for easy transportation and installation. Technical Specifications: Power Range: Typically available in 1HP to 25HP models. Cylinder: Robust cast iron construction for long-lasting performance. Lubrication System: Splash lubrication ensures smooth operation and reduced wear. Safety Features: Equipped with safety valves and pressure gauges for secure operation. Applications: Automotive Workshops: Ideal for tire inflation, painting, and light pneumatic tools. Woodworking: Drives nail guns, staplers, and other equipment. Packaging: Supports smaller pneumatic systems for sealing and wrapping. Laboratories and Clinics: Used for operating precision instruments. Advantages: Affordable: Cost-effective solution for medium-pressure applications. Reliable: Proven design ensures dependable performance over time. Low Maintenance: Easy to service and maintain, reducing downtime.

20 HP Reciprocating Air Compressor Motor Power 20 HP Tank Capacity 500 L Brand Comptech Cooling System Air Cooled Maximum Flow Rate(CFM) 77 No. of Cylinders 3 Stages Double Stage Power Phase Three Phase reliable machine used to compress air for various applications. It works by using a piston that moves back and forth to compress the air inside a cylinder, making it ideal for powering tools, inflating tires, and more. At Comptech Equipments Limited, we provide high-quality reciprocating air compressors designed for durability, efficiency, and long-lasting performance. Perfect for industries and workshops, our compressors are easy to use and maintain.

15 HP Reciprocating Air Compressor. Motor Power : 15 HP Maximum Flow Rate : 45 cfm Discharge Pressure : 12 kg/cm2g Air Tank Capacity : 500 L Brand Name : Comptech Compressor Technology : Reciprocating Compressor Power Source : Electric Warranty : 12 months Cooling Method : Air Cooled Air Quality Standard : Class I Air Receiver with 15 HP Standard make Motor and DOL starter, complete package ready to start. Dry type Suction Air filter with silencer. Auto starts and stops system. V-belt Drive arrangement. Receiver fittings: Service valve, Safety valve, Drain valve, Pressure gauge, Belt guard.
