10 HP Tank Mounted Direct Driven Screw Air Compressor Horse Power : 10 HP Brand : Comp Tech Power Source : AC Three Phase Compressor Technology : Screw Compressor Model Name/Number : CTSD 10 Cooling Method : Air Cooled Dimension : 34 x 26 x 44 inch (L x W x H) Warranty : 12 months Weight : 400 kg Mounting Type : Tank Mounted Number Of Compression Stages : Single Stage Sound Level : 68 dB Compressor Speed : 2900 rpm FAD Capacity : 40 cfm at 8 kg/cm2, 35 cfm at 10 kg/cm2 Country of Origin : Made in India Our 10 HP Tank Mounted Direct Driven Screw Air Compressor available in Standard Fix Models. We use PM Motor with our VFD Models, which decrease the energy consumption substantially to save even more energy as well as money. Other Details: Mounted on Air Receiver Features: Super premium efficiency IE4 PM motor Vibration free quieter operation Designed for hot indian climate Service friendly design Direct drive with low rpm Advance PLC for easy operation Lowest oil carry over Lowest life cycle cost

20 HP Tank Mounted Direct Driven Screw Air Compressor Horse Power : 20 HP Model : Name/Number CTSD 20 Weight : 450 kg Compressor Technology : Screw Compressor Dimension : 36 x 30 x 43 inch (L x W x H) Warranty : 12 months Cooling Method : Air Cooled Air Quality Standard : Class I FAD Capacity : 85 cfm at 8 kg/cm2, 77 cfm at 10 kg/cm2 Number Of Compression Stages : Single Stage Mounting Type : Tank Mounted Sound Level : 70 dB Brand Name : Comptech Compressor Speed : 2900 rpm Our 20 HP Tank Mounted Direct Driven Screw Air Compressor available in Standard Fix Models. We use PM Motor with our VFD Models, which decrease the energy consumption substantially to save even more energy as well as money. Other Details: Mounted on Air Receiver Features: Super premium efficiency IE4 PM motor Vibration free quieter operation Designed for hot indian climate Service friendly design Direct drive with low rpm Advance PLC for easy operation Lowest oil carry over Lowest life cycle cost

15 HP Reciprocating Air Compressor. Motor Power : 15 HP Maximum Flow Rate : 45 cfm Discharge Pressure : 12 kg/cm2g Air Tank Capacity : 500 L Brand Name : Comptech Compressor Technology : Reciprocating Compressor Power Source : Electric Warranty : 12 months Cooling Method : Air Cooled Air Quality Standard : Class I Air Receiver with 15 HP Standard make Motor and DOL starter, complete package ready to start. Dry type Suction Air filter with silencer. Auto starts and stops system. V-belt Drive arrangement. Receiver fittings: Service valve, Safety valve, Drain valve, Pressure gauge, Belt guard.

10 HP Reciprocating Air Compressor. Horse Power : 10 HP Compressor Technology : Reciprocating Compressor Brand : Comptech Air Tank Capacity : 500 Litre Number Of Compression : Stages 2 Compressor Speed : 880 rpm Maximum Pressure : 12.3 kg/cm2g Warranty : 12 months Number Of Cylinders : 2 Power Source : Electric Air Receiver with 10 HP Standard make Motor and DOL starter, complete package ready to start. Dry type Suction Air filter with silencer. Auto starts and stops system. V-belt Drive arrangement. Receiver fittings: Service valve, Safety valve, Drain valve, Pressure gauge, Belt guard.

20 HP High Pressure Air Compressor Motor Power : 20 HP Air Tank Capacity : 500 L Maximum Flow Rate : 50 CFM Discharge Pressure : 25 bar Model Name/Number : 115TH Brand CompTech Usage/Application : Pet Bottle Blowing Power Source : AC Three Phase Air Quality Standard : Class 2 Compressor Mounting Configuration : Tank Mounted Warranty : 6 months Accessories : Filter, Dryer, Receiver Compressor Technology : Reciprocating Output Pressure : 25 Kg/ bar Other Available High Pressure Models 25 HP High Pressure Compressor 30 HP High Pressure Compressor (Duplex) 40 HP High Pressure Compressor (Duplex) 50 HP High Pressure Compressor (Duplex)

150 HP Pharma Industries Medium Pressure Oil Free 2 Stage Air Compressor • Oil Free Medium Pressure have Forged Crank Shaft & Connecting Rod, Precision Main & Crank Pin Bearings with force feed lubrication have very high load bearing capacity & hardly needs replacements. • Low RPM & rugged cast iron design ideal for heavy duty continuous 24 x 7 operating year after year. • Cylinders constructed with large cast in water jackets & specially designed intercoolers for dimensional stability & better cooling under continuous operation. Features: • 100% oil free air • Vibration free quieter operation • Sustainable design for decades • Service friendly design • Lowest area occupancy • Advance PLC for easy operation • Premium efficiency IE3 motor • Lowest life cycle cost Technical Specifications – 150 HP Oil-Free Reciprocating Air Compressor (Model: CTBO 10-150) Horse Power : 150 HP Maximum Flow Rate : 644 CFM Model Name/Number : CTBO 10-120 Brand : Comptech Air Tank Capacity : 3000 Litre Compressor Technology : Reciprocating Compressor Power Source : AC Three Phase Warranty : 12 Months Cooling Method : Water Cooled Lubrication Style : Oil Free

120 HP Pharma Industries Medium Pressure Oil Free 2 Stage Air Compressor • Oil Free Medium Pressure have Forged Crank Shaft & Connecting Rod, Precision Main & Crank Pin Bearings with force feed lubrication have very high load bearing capacity & hardly needs replacements. • Low RPM & rugged cast iron design ideal for heavy duty continuous 24 x 7 operating year after year. • Cylinders constructed with large cast in water jackets & specially designed intercoolers for dimensional stability & better cooling under continuous operation. Features: • 100% oil free air • Vibration free quieter operation • Sustainable design for decades • Service friendly design • Lowest area occupancy • Advance PLC for easy operation • Premium efficiency IE3 motor • Lowest life cycle cost Technical Specifications – 120 HP Oil-Free Reciprocating Air Compressor (Model: CTBO 10-120) Horse Power : 120 HP Maximum Flow Rate : 644 CFM Model Name/Number : CTBO 10-120 Brand : Comptech Air Tank Capacity : 3000 Litre Compressor Technology : Reciprocating Compressor Power Source : AC Three Phase Warranty : 12 Months Cooling Method : Water Cooled Lubrication Style : Oil Free

75 HP Pharma Industry Medium Pressure Oil Free Air Compressor • Oil Free Medium Pressure have Forged Crank Shaft & Connecting Rod, Precision Main & Crank Pin Bearings with force feed lubrication have very high load bearing capacity & hardly needs replacements. • Low RPM & rugged cast iron design ideal for heavy duty continuous 24 x 7 operating year after year. • Cylinders constructed with large cast in water jackets & specially designed intercoolers for dimensional stability & better cooling under continuous operation. Features: • 100% oil free air • Vibration free quieter operation • Sustainable design for decades • Service friendly design • Lowest area occupancy • Advance PLC for easy operation • Premium efficiency IE3 motor • Lowest life cycle cost Technical Specifications – 75 HP Oil-Free Reciprocating Air Compressor (Model: CTBO 10-75) Horse Power : 75 HP Air Tank Capacity : 2000 Litre Maximum Flow Rate : 324 CFM Model Name/Number : CTBO 10-75 Brand : Comptech Power Source : AC Three Phase Warranty : 12 Months Lubrication Style : Oil Free Discharge Pressure : 10 kg/cm²g

60 HP 2 Stage Medium Pressure Oil Free Air Compressor • Oil Free Medium Pressure have Forged Crank Shaft & Connecting Rod, Precision Main & Crank Pin Bearings with force feed lubrication have very high load bearing capacity & hardly needs replacements. • Low RPM & rugged cast iron design ideal for heavy duty continuous 24 x 7 operating year after year. • Cylinders constructed with large cast in water jackets & specially designed intercoolers for dimensional stability & better cooling under continuous operation. Features: • 100% oil free air • Vibration free quieter operation • Sustainable design for decades • Service friendly design • Lowest area occupancy • Advance PLC for easy operation • Premium efficiency IE3 motor • Lowest life cycle cost Technical Specifications – 60 HP Oil-Free Reciprocating Air Compressor (Model: CTBO 10-50) Horse Power : 60 HP Brand : Comptech Air Tank Capacity : 1000 Litre Maximum Flow Rate : 273 CFM Discharge Pressure : 10 kg/cm².g Model Name/Number : CTBO 10-60 Lubrication Style : Oil Free Warranty : 12 Months Compressor Technology : Reciprocating Compressor Cooling Method : Water Cooled
